D-Sub interfaces with a firm screw locking between connector hood and counter-connector are indispensable for all applications being exposed to e.g. mechanical stress (vibration, traction, bending) or significant temperature variations, but which are nevertheless supposed to provide reliable locking, free from clearance.

Hence, a screw-locked interface does not only ensure a reliable electrical contacting between the connectors. In combination with a full metal hood they also improve the ground contact and thereby the EMC of the interconnection.

Furthermore, the screw connections have to allow a quick and simple assembly; they should not corrode under adverse environmental conditions and should be easily un- and re-tightened even after a longer period of installation.

As a specialist for EMI / RFI shielding interconnection systems Inotec electronics offers the widest product range of full metal hoods for D-Sub connectors with its series MS, MSX, MSB and MSBS.

MS series

MS series with screw locking for 9- up to 50-way D-Sub or 15- up to 78-way HD connectors

• Save and vibration-resistant connection with highest mechanical resilience
• Locking screws are retained and secured against loss
• All screws are available in 4-40 UNC or M3 threading with various head shapes
• Extended version available, suitable for integrated PCB or special wiring solutions
• Optionally available with preparation for the Inotec coding system
• DG09MS-61 suitable as counter connector hood for 9-way D-Sub or HD15 connectors

MSX series

MSX series with screw locking for 9- up to 50-way D-Sub or 15- up to 78-way HD and 104-way connectors

• Save and vibration-resistant connection with highest mechanical resilience
• Extended “close the gap” blanket for an interference-free connection to a terminal device
• Large interior space e.g. for installation of mixed connectors or integration of PCB
• Pre-assembled and retained M3 screws with sealing bores
• Up to 3 cable entries for highest flexibility

MSB series

MSB series - the universal BUS connector hood for 9- and 15-way D-Sub or 15- and 26-way HD connectors

• Locking screws with 4-40 UNC or M3 thread, pre-assembled with integrated retention
• Two steplike 30° cable inlets do permit a space-saving cable routing
• Compact outer dimensions permit a closely packed side-by-side mounting
• Spacious interior for easy integration of PCB’s
• Long blanket for efficient shielding even in high interference levels
• Upon request Inotec provides completely assembled MSB connectors for all common BUS systems

MSBS series

MSBS series – compact BUS hood for extremely limited installation spaces. For 9-way D-Sub or 15-way HD connectors

• Compact design allows a high packing density
• Two parallel 30° cable outlets for a maximum installation space inside of the hood
• Special crimp flange geometry CF400 for BUS cables
• Free access to locking screws, even in installations with limited access
• Fully compatible with Inotec coding system
• Long blanket for safe shielding even against high disturbance levels

MSBS series as BUS connectors

MSBS series – completely assembled BUS connectors

• For all common BUS systems e.g. PROFIBUS, CAN, MVB / WTB
• Suitable for field assembly, traction relief and shield connection with Inotec crimp flange CF400
• Quick and safe wire connection with integrated cage clamp terminals
• Available either as male or female type with 4-40 UNC or M3 locking screws
• Also available completely equipped with the original Inotec coding system

DGA series

DGA series – adaptor hoods for special applications

• Full metal hoods for a variety of applications
• Extremely low-rise M11 series is particularly suitable as space-saving diagnostic plug or also as piggy-back connector or gender changer
• M30 series with its spacious interior can be equipped with complete circuits or complex cablings
• Locking screws with female threaded head for piggyback assembly
• Modified version for attachment of blind plates with integrated snap-on hook
